Installation record
Page 73
8 Installation record
The following installation record should be completed and retained on board the vessel once the AIS
transceiver has been installed and commissioned.
Vessel details
Vessel name
Flag state
IMO number MMSI number
Owner Radio call sign
Type of vessel Gross registered tonnage
Length (m) Beam (m)
AIS transceiver serial number
(see underside of transceiver or packaging
label)
Junction box serial number (see label on junc-
tion box)
Installation password (if changed from default)
Transceiver software version number
UI software version number
GPS / GNSS antenna locations
Internal GPS antenna location (all dimensions in meters, refer to the diagram below)
A= B= C= D=
External GNSS antenna location (all dimensions in meters, refer to the diagram below)
A= B= C= D=
Ref A
Antenna
Ref A + Ref B = Length in metres Ref C + Ref D = Beam in metres
Ref B
Stern Bow
Ref C
Ref D
