DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-13
“R16UM0.F21“ in the lower part of the screen. KSU Revision is the DX-80 software and “R16UMx.xxx” is
the PC-DBA version.
• Use ¢£¤¥ to select the appropriate Maintenance utility and then press «. Each utility is
described below.
Configuration
When “Configuration” is selected, the DX-80 processor sends the current hardware configuration to PC-
DBA for viewing. For each Board viewed the Type is displayed so that the hardware can be readily
identified. The Option Board can show three Board Types:
Option Board Type Description
AAM Automated Attendant Module
FL-VM Flash Voice Mail (with Automated Attendant)
PC-8 8-Port Hard Drive Voice Mail (with Automated Attendant)
Board Status can be any of the following:
Board Status Description
Fail/Failed This board is reporting some failure as a result of the last diagnostic
test. Also, this can indicate that CO lines are not connected to a CO
port or that Loop Current is no longer present on the CO lines
connected.
Open The board position is Open (not occupied, and likely never occupied).
Connect This board is reporting connected (installed and normal) status
Disconnect This board has been installed and is now removed.
Block/Unblocked This board/port is Blocked/Unblocked as part of a Maintenance
service function.
