DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 3-78
2. Press [cbck ]. The display shows: CBCK TO LINE XX momentarily and then goes idle.
Operation – Queue Callback Answer
1. When the CO Line queued becomes idle, it will Callback ring the extension. The display shows:
CBCK TO LINE XX
reply del
2. The user may lift the handset, press the ON/OFF button to activate speakerphone or press [reply ] to
answer the Queue Callback.
Conditions
An extension must have access to a CO Line via Line Assignment to Queue a CO Line.
Default Settings
N/A
Programming Abstract
No Programming is required for CO Line Queuing.
CO Line Receive Assignment
CO Line Receive Assignment is the DX-80 system utility used to allow an extension to answer ringing CO Lines. The
DX-80 system allows the Receive Assignment of CO Lines to extensions in a matrix fashion such that complete
flexibility is possible. Each CO Line may be assigned individually as a Receive Assigned – Yes or No.
When ringing occurs on a CO Line that is Receive Assigned – No; the LED for the CO Line lights busy while the line
is ringing.
Related Features
Tenant Group CO Line Private Line
CO Line Group
Related Programming
Extension – Receive Assignment
CO Line – Tenant Group, CO Line Group, Private To
Conditions
Receive Assignment does not inhibit a user from accessing a CO Line for out-calling.
Default Settings
All DX-80 extensions are Receive Assigned – Yes to all CO Lines.
Programming Abstract
Program the required extensions for Receive Assigned – No per CO Line.
Programming via the DET (Digital Extension Terminal)
Note: [back], [next], [show], [chg], [bksp], and [save] are LCD interactive button operations. Use the
three buttons below the LCD display to actuate the associated operation.
• Enter Database Administration using the feature code !+* and then enter the DB Admin password
“++++++++.” (Note: This eight-character password can be changed.)
• Press [show ]. The DB Item Select screen displays.
