DX-80 INSTALLATION AND MAINTENANCE MANUAL
P7290 IMM 4-25
+--------------------+
¦ Event ¦
+--------------------¦
¦ Event Invoking ¦
¦ Event Deleting ¦
+--------------------+
+--------------------------+
¦ Maintenance ¦
+--------------------------¦
¦ +-------------------+-------------------+
+---------------------------------------¦ Pseudo ¦
¦ Event Selection ¦ Extension ¦
+---------------------------------------¦ CO Line ¦
¦ Start Event : ¦ Modem Status ¦
¦ ¦ Timing ¦
+---------------------------------------¦ AAM ¦
+-------------------------+-------------------+
+--------------------------+
¦ Maintenance ¦
+--------------------------¦
¦ +-------------------+-------------------+
+---------------------------------------¦ Feature Key ¦
¦ Event Selection ¦ DSS Key ¦
+---------------------------------------¦ Dial Key Pad ¦
¦ Start Event : ¦ Special Key ¦
¦ ¦ Function Key/Code ¦
+---------------------------------------¦ Ring Status ¦
+-------------------------¦ Timeout ¦
+-------------------+
+------------------------------------+
¦ Feature Key 1 Feature Key 17 ¦
¦ Feature Key 2 Feature Key 18 ¦
¦ Feature Key 3 Feature Key 19 ¦
¦ Feature Key 4 Feature Key 20 ¦
¦ Feature Key 5 Feature Key 21 ¦
¦ Feature Key 6 Feature Key 22 ¦
¦ Feature Key 7 Feature Key 23 ¦
¦ Feature Key 8 Feature Key 24 ¦
¦ Feature Key 9 Feature Key 25 ¦
¦ Feature Key 10 Feature Key 26 ¦
¦ Feature Key 11 Feature Key 27 ¦
¦ Feature Key 12 Feature Key 28 ¦
¦ Feature Key 13 Feature Key 29 ¦
¦ Feature Key 14 Feature Key 30 ¦
¦ Feature Key 15 Redial Key ¦
¦ Feature Key 16 Mute Key ¦
+------------------------------------+
Extension selected
to start event
output.
Feature Key selected to start
event output. Then a specific key
is selected to start the event
output through the “SMDR” serial
port.
Important: data must be collected
in a dedicated collection PC using
a special Event Tracking software
or a terminal emulation software
that writes to a text file for later
deciphering at customer service.
