Comelit Ultra Simplebus2 - Special Programming Table

22
Special programming table
CODE DIP SWITCHES ON FUNCTIONS
Audio-visual messages
193 1,7,8 Czech
195 1,2,7,8 Hebrew
196 3,7,8 Polish
197 1,3,7,8 Catalan
198 2,3,7,8 Galician
199 1,2,3,7,8 Basque
206 2,3,4,7,8 Danish
207 1,2,3,4,7,8 Norwegian
211 1,2,5,7,8 Swedish
215 1,2,3,5,7,8 Italian
216 4,5,7,8 French
217 1,4,5,7,8 Spanish
218 2,4,5,7,8 Dutch
219 1,2,4,5,7,8 Greek
220 3,4,5,7,8 English
221 1,3,4,5,7,8 German
222 2,3,4,5,7,8 Portuguese
202 2,4,7,8 Enables voice message (door opened warning) when the RTE contact is closed
203 1,2,4,7,8
Disables voice message (door opened warning) when the RTE contact is closed
(default setting)
210 2,5,7,8 Enables visual messages and disables voice messages (default)
214 2,3,5,7,8 OFF: disables voice and visual messages
Actuator control management
N.B. the system should not include art. 1256 in generic actuator mode.
229 1,3,6,7,8 C.NC.NO relay activation on actuator command: 2 sec (default)
230 2,3,6,7,8 C.NC.NO relay activation on actuator command: 4 sec
231 1,2,3,6,7,8 C.NC.NO relay activation on actuator command: 8 sec
Door lock
184 4,5,6,8 Door lock time: 100 msec
185 1,4,5,6,8 Door lock time: 200 msec
186 2,4,5,6,8 Door lock time: 500 msec
245 1,3,5,6,7,8 Door lock time: 2 sec + disabling tone (default)
246 2,3,5,6,7,8 Door lock time: 4 sec
247 1,2,3,5,6,7,8 Door lock time: 8 sec
248 4,5,6,7,8 Door lock confirmation tone: enabled
252 3,4,5,6,7,8 Lock-release always enabled (default)
253 1,3,4,5,6,7,8 Lock-release only enabled for user called
System functions
232 4,6,7,8 Awaiting response time: 60 sec (default)
233 1,4,6,7,8 Awaiting response time: 120 sec
234 2,4,6,7,8 Awaiting response time: 30 sec
235 1,2,4,6,7,8 Talk time: 90 sec (default)
236 3,4,6,7,8 Talk time: 180 sec
145 1,5,8 RTE input set as local lock-release input (default)
146 2,5,8 RTE input set as door open indication
154 2,4,5,8 System busy signalling time: 10 sec (default)
155 1,2,4,5,8 System busy signalling time: 300 sec
239 1,2,3,4,6,7,8
Confirmation tone on user call = enabled
(default)
240 5,6,7,8 Confirmation tone on user call = disabled
