EVENTS
You can set the several functions to be executed when specific events occur. Up to 20 events can be set.
EVENTS
• No.: select the progressive number of the event
• Action: select the action triggering the event
◊ None: no action (default)
◊ Call sent: if a call is sent to a door-entry phone with an address that falls within the values entered in
the “From address” and “To address” fields, it triggers the event specified in the “Activation” field
◊ Lock-release: if a lock-release command is sent from a door-entry phone with an address that falls
within the values entered in the “From address” and “To address” fields, it triggers the event specified
in the “Activation” field
◊ Actuator control: if an actuator command is sent with an address that falls within the values entered in
the “From address” and “To address” fields, it triggers the event specified in the “Activation” field
• Activation: action triggered after the event specified in the “Action” field occurs
◊ Local output control: activates the output set in the “Local output type” field (SE output for the
module or Relay output for the module). NOTE: Module SE Output and/or module Relay Output must
be set in the menu “Outputs” > SE Output and/or Relay Output with “Function” > Lock-release and/or
actuator
◊ Control on Ultra bus (UDB): activates the relay on the number keypad specified in the “Device type”
field (UDB output type: Relay 1 or Relay 2)
◊ Actuator control: activates the actuator with the address specified in the “Address” field (from 1 to
255)
• Activation
◊ Local output control (non-editable)
• Local output type
◊ Relay (non-editable)
• Enable Tones: a confirmation tone is emitted when the output is activated for the time period set in the
“Activation time (sec.)” field
VIRTUAL OUTPUT 1 / VIRTUAL OUTPUT 2
• Function: select the command which activates the virtual output for the audio module. The virtual outputs
are NOT physically part of the module, they are commands sent over the bus.
◊ Lock-release: every lock-release command activates the output
◊ Actuator control: every actuator command with the address set in the “Address sent to external unit”
field activates the output
◊ Call sent: every call sent activates the output
• Activation
◊ Local output control: activates the output set in the “Local output type” field (SE output for the
module or Relay output for the module)
◊ Control on Ultra bus (UDB): the command activates the relay on the Module keypad specified in the
“Device type” field (UDB output type: Relay 1 or Relay 2)
◊ Actuator control: the command activates the actuator with the address entered in the “Address” field
• Enable tones: a confirmation tone is emitted when the output is activated for the time period set in the
“Activation time (sec.)” field
