Use only the supplied power supply FRIWO FW7555M/09 . The use of other units
could lead to electric shock or damage to the instrumentation.
4. open the control program and follow the third party software indication for data graphic render-
ing and digital data collection.
The operation of the system Wave Plus is now under the control of the Personal Computer. Refer to
the User Manual supplied by the manufacturer of third party software for the description of the oper-
ational commands. The following table gives the references:
Software Code: NA
Release: NA
Manufactured by: NA
When operating in digital mode, the device is powered directly from the PC via the
USB interface; for correct operation, the connection must provide the rated current
provided by the USB II specification(500mA). In this case, the use of the external
power supply is optional, and the computer must be powered via an isolation trans-
former or power supply according to IEC60601-1.
You can also use a personal computer equipped with USB ports with reduced current
(100mA), in which case you must connect, in addition to the USB cable, the external
power supply.
4.2.1 External trigger
Wave Plus has a connector for external trigger of data capture. External trigger lines are
not insulated from the Wave Plus system ground.
The use of external devices not complying with IEC 60950 can cause electric shock and
damage the system.
Pin out of the trigger jack:
