COMETA WAVE PLUS - Electrode Battery Specifications

WAVE PLUS - USER MANUAL
COD. WPMEMG
REV 01
02/11/2011
DATA PRIMA EMISSIONE
Pag. 28 di 37
6. Take the
new battery
and follow the
same steps
backwards to
install it inside
the probe.
7. Carefully in-
sert the new
battery, mak-
ing sure it is
positioned as
shown in the
picture.
8. Put the
probe back to-
gether by slid-
ing the upper
part back into
the lower one,
as shown in the
picture, until
you hear a
click.
5.3 Electrode battery characteristics
Voltage: 4V
Capacity: 150 mA/h
Type: LI – ION rechargeable battery
Max. Recharging cycles: 300 (80% residual capacity)
