event of the beginning and the end of the data acquisition or, in general, a temporal reference event
(e.g. the timing of the TMS stimulation) can be directly saved into the same data streaming.
The scheme above shows the required connections to realise this type of synchronism in case:
1. The third-party device is working as master: red connection;
2. The Wave Plus system is working as master: blue connection
.
NOTE THAT if you want synchronize the Wave Plus system with third-party devices collecting the
EMG signals from the Wave Plus analogue port, you should also consider the 13 ms delay related to
the Wave Plus analogue output. In this case you should correct the recorded data in order to remove the
13 ms delay. NOTE THAT the 14 ms delay is constant and it can be easily removed by shifting the
temporal sequence in the following way:
NOTE THAT the delay does not produce a loss of acquired data at all.
Please, for further details contact Cometa.
4.2.2 Supported external devices
Wave Plus system can be connected to any PC with USB interface; these are the features required by
systems:
Type 2 USB interface
Windows 2000 or XP
VGA graphic card with a resolution of at least 1024 x 768
Minimum ram memory, 512 MB
Minimum processor frequency, 800 MHz
Minimum hard disk, 20 GB
