Basic user – Web interface Symphony BF
18 1.4/0222
Door Opener Timer (s): In this field, the time can be changed (in seconds) how long the relay shall
stay active after pressing the door opener button. default: “2”
In the drop-down lists, the following relay modes can be selected for the call states listed above:
Nothing: Deactivate attendant contact (relay not used).
On: Close relay output (activate).
Off: Open relay output (deactivate).
Flashing: Switch relay output to blinking (switch on and off in rhythm of one second).
Door Opener: Relay output is closed for a configurable time (see page 18
).
EB2E2A Relay 1 and EB2E2A Relay 2
If an option board EB2E2A is connected to the expansion jack of the station, two additional relay out-
puts are available.
NOTE:
If the current state of the attendant contact changes while the door opener timer is active, the relay
will be triggered immediately (i.e. before the configured door opener timer has expired).
NOTE:
The configuration is the same as for the relays of the Symphony BF device (see page 17).
