OTY. REO. PER DASH # ITM
PART NO.
DESCRIPTION10
0£
o e
07
06
05
04
03
02 01
tt
REF D ES/N O TE S
-
R 1
365377-01 SCHEMATIC, VIDEO SYNC DONGLE
-
R
2
365379-01
PCB FAB, VIDEO SYNC DONGLE
-
R
3 365381-01 FUNCTIONAL SPEC , VIDEO SYNC DONGLE
-
1
4
365104-01
ARTWORK, VIDEO SYNC DONGLE PCB
5
R
-
6
365377-02
SCHEMATIC, VIDEO BUFFER DONGLE
R
-
7 M WN/Af-««-
PCB FAB, VIDEO BUFFER DONGLE
1
-
8
ARTWORK, VIDEO BUFFER DONGLE PCB
9
—v
-------
r 1—
10
11
. . INTEGRATED CIRCUITS
12
' i *
-
1
13
391695-01 IC. SM, MPU, OTP, XC68HC705K1DW
U1 - Program m od into 391694-01
-
S 14
391696-01 IC. SM. MPU, MASKED, XC68HC705K0DW
Su b for item 13
15
-
1
16
391395-01
IC, SM, 74HC157
U2
1
.
17
380227-12
IC. 74HCT08
[U l]
S
-
18
??
IC, SM .74H C 08
[U l] Sub lor ilem 17
19
20
PASSIVE COMPONENTS
21
-
1 22
310026-28
RESISTOR. SM. 1 20 6 ,1 5 K ohm
RI
-
1
23
310026-16 RESISTOR, SM, 1206, 2.7 K ohm
R2
-
1 24
310026-36
RESISTOR, SM. 1206, 910 ohm
R3
-
1
25 310026-17
RESISTOR, SM, 1 206 ,1 0 K ohm
R4
26
-
3
27
310027-02
CAPACITOR, SM. 25U , 1206, 0.1 UF. 25V
C 1.C 2.C 5
-
1
28
390853-07
CAPACITOR, SM, X7R, 1206, 1000 PF
C3
-
1
29
390818-06 CAPACITOR, SM. NPO, 12 0 6,100 PF
C4
1
-
30
900010-38 CAPACITOR. CERAMIC DISK, SL/B/V 0.01 UF
[C I] (50V 25U)
31
-
2 32
391129-01
DIODE, SM, 1N 4148, SOT23
0 1 ,0 2
33
-
5
34
391092-02 FILTER FERRITE, SM, MEDIUM, 1206
F B I-F B 5
35
36
37
CONNECTORS
38
1 1
39 390241-08 CONNECTOR, D-SUB, RA, 23P
CN1
1 1
40 390344-01 CONNECTOR, D-SUB, RA, 15P, VGA CN2
41
42
43
44
45
46
47
48
49
50
Commodore
Tille
PCBA, VIDEO DONGLES (SYNC & BUFFER)
Orawn by
D .S h ann o n
Drawlng ä
365380
REV
A
Sheot 2 o f 2
