IFC OR OSP
CABLE
A
B
B
C
C
SHEATH
45.0 IN.
(114.3 CM)
64.0 IN.
(162.6 CM)
19.0 IN.
(48.3 CM)
SUB-UNITS
FIBERS
CONNECTORS
24573-A
ROUTED
FROM BOTTOM
A
RADIUS
LIMITERS
ADCP-90-545 • Issue 4 • July 2016
Page 20
© 2016 CommScope. All Rights Reserved.
Figure 17. Field Termination Breakout and Routing, 12-Fiber Wall-Mount Box (Bottom Entry)
