CommScope FL1000 - Page 21

24578-A
RADIUS
LIMITER
PLACE GROMMETS
ON EACH RADIUS
LIMITER BEHIND
AND IN FRONT OF
SPLICE TRAY
ROUTED FROM TOP
ROUTED FROM BOTTOM
IFC OR OSP
CABLE
A
B C
SHEATH
36 IN. MIN.
(91.44 CM)
63 - 69 IN.
(160 - 175 CM)
SUB-UNITS
FIBERS
CORNER OF
SPLICE TRAY
ADCP-90-545 • Issue 4 • July 2016
Page 21
© 2016 CommScope. All Rights Reserved.
Figure 18. Splicing Breakout and Routing, 12-Fiber Wall-Mount Box
