Comnet CWGE2FE8MSPOE - Page 12

5
DRAM
32Mbytes
Connector
100Base-T: 8x RJ-45 with auto MDI/MDI-X and PoE
inject function
10/100/1000T/ 100/1000Mini-GBIC Combo: 2 x RJ-45 + 2
x 100/1000 SFP sockets
PoE Pin Assignment
RJ-45 port # 1~# 8 support IEEE 802.3af End-point,
Alternative A mode.
Per port provides 15.4W ability
Positive (VCC+): RJ-45 pin 1, 2
Negative (VCC-): RJ-45 pin 3, 6
LED
System Power (Green)
10/100TX Port: Link/Activity (Green), 100Mbps (Green),
PoE (Green).
Gigabit copper port: 1000/100Mbps (Green), Link/Activity
(Green),
100/1000Mini-GBIC: Link/Activity (Green).
RS-232 Connector
One RS-232 DB-9 Female connector for switch
management
Power
48VDC @ 2A
Power Consumption
81.3 Watts for the system (maximum)
Ventilation
Fanless
