Port Trunk—State Activity
Having set up the LACP aggregator on the tab of Aggregator Setting, you can configure
the state activity for the members of the LACP trunk group. You can select or cancel the
checkbox beside the state label. When you remove the select mark of the port and click
, the port state activity will change to Passive.
 Active: The port automatically sends LACP protocol packets.
 Passive: The port does not automatically send LACP protocol packets, and
responds only if it receives LACP protocol packets from the opposite device.
[NOTE]
A link having two passive LACP nodes will not perform dynamic LACP
trunk because both ports are waiting for an LACP protocol packet from the
opposite device.
State Activity of Switch 1
