1 is 10Mbps, users can set it’s effective egress rate is 1Mbps, ingress rate is
500Kbps. The switch performs the ingress rate by packet counter to meet the
specified rate
Ingress: Enter the port effective ingress rate (The default value is “0”).
Egress: Enter the port effective egress rate (The default value is “0”).
And then, click to apply the settings
VLAN configuration
A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain, that
would allow you to isolate network traffic, so only the members of the same VLAN will
receive traffic from the ones on the same VLAN. Basically, creating a VLAN on a switch is
the logical equivalent of reconnecting a group of network devices to another Layer 2
switch. However, all the network devices are still physically plugged into the same switch.
This switch supports Port-based and 802.1Q (tagged-based) VLAN. The default
configuration of VLAN operation mode is “Disable”.
VLAN Configuration interface
