Service Reference Guide, dx2000 uT 359782-002 6–17
Removal and Replacement Procedures— Microtower (µT) Chassis
6.11 System Fan
1. Prepare the computer for disassembly (Section 6.1, “Preparation for Disassembly”).
2. Remove the right access panel (Section 6.2, “Access Panel”).
3. Disconnect the cable that connects the system fan to the system board.
4. Remove the four screws that secure the fan to the chassis and remove the fan.
To install the fan, reverse the removal procedures.
