Compaq EN Series User Manual

Appendix A Error Messages and Codes
Compaq Personal Computers
Changed - April 1998
A-6
A.10 DISKETTE DRIVE ERROR MESSAGES (6xx-xx)
Table A–9.
Diskette Drive Error Messages
Table A-9.
Diskette Drive Error Messages
Message Probable Cause Message Probable Cause
6xx-01 Exceeded maximum soft error limit 6xx-20 Failed to get drive type
6xx-02 Exceeded maximum hard error limit 6xx-21 Failed to get change line status
6xx-03 Previously exceeded max soft limit 6xx-22 Failed to clear change line status
6xx-04 Previously exceeded max hard limit 6xx-23 Failed to set drive type in ID media
6xx-05 Failed to reset controller 6xx-24 Failed to read diskette media
6xx-06 Fatal error while reading 6xx-25 Failed to verify diskette media
6xx-07 Fatal error while writing 6xx-26 Failed to read media in speed test
6xx-08 Failed compare of R/W buffers 6xx-27 Failed speed limits
6xx-09 Failed to format a tract 6xx-28 Failed write-protect test
6xx-10 Failed sector wrap test -- --
600-xx = Diskette drive ID test 608-xx = Diskette drive write-protect test
601-xx = Diskette drive format 609-xx = Diskette drive reset controller test
602-xx = Diskette read test 610-xx = Diskette drive change line test
603-xx = Diskette drive R/W compare test 694-00 = Pin 34 not cut on 360-KB drive
604-xx = Diskette drive random seek test 697-00 = Diskette type error
605-xx = Diskette drive ID media 698-00 = Drive speed not within limits
606-xx = Diskette drive speed test 699-00 = Drive/media ID error (run Setup)
607-xx = Diskette drive wrap test
A.11 SERIAL INTERFACE ERROR MESSAGES (11xx-xx)
Table A–10.
Serial Interface Error Messages
Table A-10.
Serial Interface Error Messages
Message Probable Cause Message Probable Cause
1101-01 Port test, UART DLAB bit failure 1101-12 Port test, DRVR/RCVR cntrl. signal failure
1101-02 Port test, line input or UART fault 1101-13 Port test, UART cntrl. signal interrupt failure
1101-03 Port test, address line fault 1101-14 Port test, DRVR/RCVR data failure
1101-04 Port test, data line fault 1109-01 Clock register initialization failure
1101-05 Port test, UART cntrl. signal failure 1109-02 Clock register rollover failure
1101-06 Port test, UART THRE bit failure 1109-03 Clock reset failure
1101-07 Port test, UART Dta RDY bit failure 1109-04 Input line or clock failure
1101-08 Port test, UART TX/RX buffer failure 1109-05 Address line fault
1101-09 Port test, interrupt circuit failure 1109-06 Data line fault
1101-10 Port test, COM1 set to invalid INT 1150-xx Comm port setup error (run Setup)
1101-11 Port test, COM2 set to invalid INT -- --
