External Device Connections
Hardware Guide 7–3
For more information about using the modem or about using
AT commands and dial modifiers, refer on this CD to the
Modem and Networking guide or the Modem Commands guide.
Connecting a Network Cable
A network cable has an 8-pin RJ-45 connector at each end and
may contain noise suppression circuitry, which prevents
interference with TV and radio reception.
1. Orient the end of a network cable with noise suppression
circuitry
1
toward the RJ-45 jack on the computer.
2. Plug the network cable into the RJ-45 jack
2
.
3. Plug the other end of the cable into a network jack
3
.
4. Start or restart the computer.
5. Connect to the network.
Connecting a network cable
For more information about using a network, refer to the Modem
and Networking guide on this CD.
229045-002.book Page 3 Friday, September 21, 2001 11:16 AM
