Specifications
Size 15.4 x 13 x 3.5 cm
Weight 610 g
Operating temperature From -20°C to 60°C
Displa
y
Active-matrix TFT, 5.7’’ diagonal
Resolution 640x480
65536 colours
Automatic backlight control
Touch panel
GPS Channels:
51 independent channels with WAAS/EGNOS
Sensitivity:
-158 dBm in tracking mode; -146 dBm in acquisition
Acquisition: Cold Start: 36 s; Warm Start: 33 s; Hot Start: 1 s (open sky).
Updates: 5 points per second
Battery Li-ion, 3.7 V 6800 mAh
Altimeter From 0 to 8000 m
Variometer Resolution: 0.1 m/s, with configurable audio profile
Memory Flight logs: 170 Mb (approx 300 flight hours at 5 points per second)
USB: 840 Mb
Connectivity Serial: RS232, jack (2.5 mm) connector
USB: Profile: mass storage device
Bluetooth: Class 1
Serial port profile, Object push profile
