Technical Information on On-board Flash Programmer FP-40 Aug. 31, 2023 (Second edition)
14
■ FP-40 target interface specifications
This chapter describes the target interface specifications for connecting FP-40 to the target.
Specifications of the target connector
The standard interfaces supported by FP-40 are JTAG and SWD, and the connector specification is MIL 20-pin with
2.54mm pitch. Connection to the target system is made using the supplied dedicated interface cable (TARGET cable).
For interfaces other than JTAG and SWD, please refer to their individual instruction manuals.
Pin allocation
The pin allocations are specific to FP-40 and the target cable is dedicated to FP-40. Make sure that you only use
the TARGET cable that is included with the product.
