Computex FP-40 - Usage Environment Check Chart

Technical Information on On-board Flash Programmer FP-40 Aug. 31, 2023 (Second edition)
3
Check the table of connector
signals.
Also consult Target connection
reference diagram.
■ FP-40 usage environment check chart
The following chart table summarizes the conditions required to connect a CPU employing a Cortex core to FP-40.
With reference to the chart below, check to see if the current environment is suitable for FP-40 use.
① SWD interface
②
JTAG interface
③ SWD interface
④
JTAG interface
⑤ SWD interface
⑥
JTAG interface
* If you are using a CPU that requires TRST, ⑤JTAG interface cannot be used; TRST is not
provided for SWJ-PRB-MIL20-10HP.
Type of connector mounted on
the target system
20-pin 2.54mm-pitch connector
Required optional
product
No optional product required
20-pin 1.27mm-pitch connector
SWJ-PRB-MIL20-20HP
10-pin 1.27mm-pitch connector
SWJ-PRB-MIL20-10HP
