Computex FP-40 - Dimensions of TARGET Cable

Technical Information on On-board Flash Programmer FP-40 Aug. 31, 2023 (Second edition)
15
No. Signal
*1
Input/
Output
*2
FP-40 internal circuit
access point
20-pin
2.54mm-pitch
20-pin
1.27mm-pitch
10-pin
1.27mm-pitch
1
VTref
Output
4KΩPull-Down
1
1
1
2 X3.3V Input
Power supply
(when output is permitted)
2 - -
3
TRST / (EX_BSY)
Input
22Ωseries
3
16
-
4
GND
GND
4,6,8,10,12,14
3,5,9,11,13,15,17,19
3,5,9
5
TDI / (EX_NG)
Input
22Ωseries
5
8
8
6
GND
GND
4,6,8,10,12,14
3,5,9,11,13,15,17,19
3,5,9
7 TMS/SWDIO
Input /
Input/Output
22Ωseries
10KΩPull-Up (VTref)
7 2 2
8
GND
GND
4,6,8,10,12,14
3,5,9,11,13,15,17,19
3,5,9
9
TCK/SWCLK
Input
22Ωseries
9
4
4
10
GND
GND
4,6,8,10,12,14
3,5,9,11,13,15,17,19
3,5,9
11 (EX_STARTn) Output
1KΩseries
10KΩPull-Up (VTref)
11 - -
12
GND
GND
4,6,8,10,12,14
3,5,9,11,13,15,17,19
3,5,9
13 TDO/SWO Output
22Ωseries
10KΩPull-Up (VTref)
13 6 6
14
GND
GND
4,6,8,10,12,14
3,5,9,11,13,15,17,19
3,5,9
15 SRSTn Input
100Ωseries
Open-collector output
15 10 10
16
(EX33_BSY)
Input
100Ωseries
16
3,5,9,11,13,15,17,19
3,5,9
17
(EX_OK)
Input
22Ωseries
17
-
-
18
(EX33_OK)
Input
100Ωseries
18
3,5,9,11,13,15,17,19
3,5,9
19 (EX33_STARTn) Output
1KΩseries
10KΩPull-Up (3.3V)
19 - -
20 (X5V) Input
Power supply
(when output is permitted)
20 - -
*1 : Signal names in parentheses ( ) are signals with FP-40's unique specifications.
*2 : Input/Output is based on the target system.
Dimensions of TARGET cable
Dimensions of the dedicated TARGET cable are as follows.
