MODEL 2200
www.comtecltd.com For Kasco Corp use only.
4
INSTALLATION OF DIES
NEVER INSTALL DIES WITH THE MACHINE TURNED ON AND THE MOTOR
RUNNING !
For single-pressing round dies, follow the installation procedure below (Single-Pressing
Round Die Installation). For non-round and multi-pressing dies, follow the installation
procedure on page 6 (Non-round and Multi-Pressing Die Installation).
Single-Pressing Round Die Installation
he following procedures can be used to install all sizes and types of round
single-pressing dies, and tooling, supplied by COMTEC for your Press. We
will assume the Press does not have a set of dies installed at this time.
1. Switch Power Off. Use the power switch at the control panel on top of the
Press.
CAUTION: MAKE SURE THAT THE POWER TO THE PRESS IS OFF BEFORE
ATTEMPTING TO INSTALL A DIE.
2. Examine your dies. Make sure that both hubs are clean. While both hubs should
be clean, be especially certain that the upper die is clean. If the hub of the upper die
is coated with dough or other foreign material, the die may not heat properly (See
Figure 13).
3. Make sure that the circular hub on the heater assembly and all locating holes on
the rectangular travel plate are clean.
4. Fit the tail of the lower die half into its hole in the center of the rectangular travel
plate. (See Figure 3)
