DMD1050 Satellite Modem Board Web Browser
PORT 2 STATUS {See the note above}
Displays the current status of LAN Port 2.
WAN STATUS {See the note above}
Displays the current status of the WAN Port.
Event Menu
Figure 7-21. Event Menu
Delete All: Cleans the entire event buffer.
Event Type:
I Informational
Y Yellow alarm. Indicates a transmit or receive warning condition.
R Red alarm. Indicates a transmit or receive failure,
losing traffic.
The Event Buffer may be sorted by warning level, time, date, or event
description. This feature may be used to further investigate event
occurrences.
MN-DMD1050 7–36
Revision 9
