Chapter 4. Rear Panel Interface
This section discusses the electrical interfaces available from the rear panel. All locations are as
viewed from the rear of the unit unless otherwise specified.
4.1 DMD1050 Connections
All DMD1050 connections are made to labeled connectors located on the Modem Board. (refer
to Figures 4-1, 4-2, 4-3 and 4-4). The connector definitions below are those on the DMD1050
unit. Any connection interfacing to the DMD1050 must be the appropriate mating connector.
Refer to Appendix E for various connectors that will be used to operate the DMD1050.
The DMD1050 consists of two PC board assemblies.
• RF Board (ASR5776)
• Baseband Board (AS/5780)
MN-DMD1050 4–1
Revision 9
