DMD1050 Satellite Modem Board Technical Specifications
OQPSK SEQ 7/8 8400 2048000
OQPSK TPC 1/2 4582 9545454
OQPSK TPC 3/4 7200 15000000
OQPSK TPC 7/8 8400 17500000
8PSK TRE 2/3 9600 20000000
8PSK TPC 3/4 10800 20000000
8PSK TPC 7/8 12600 20000000
16QAM VIT 3/4 14400 20000000
16QAM VIT 7/8 16800 20000000
16QAM TPC 3/4 14400 20000000
16QAM TPC 7/8 16840 20000000
6.9.2 DVB
187 Mode
Modulation Code Rate Min Data Rate Max Data Rate
BPSK VIT 1/2 2400 4583333
BPSK VIT 2/3 2934 6111111
BPSK VIT 3/4 3300 6875000
BPSK VIT 5/6 3667 7638888
BPSK VIT 7/8 3850 8020833
QPSK VIT 1/2 4400 9166666
QPSK VIT 2/3 5867 12222222
QPSK VIT 3/4 6600 13750000
QPSK VIT 5/6 7334 15277777
QPSK VIT 7/8 7700 16041666
8PSK TRE 2/3 8800 18333333
8PSK TRE 5/6 11000 20000000
8PSK TRE 8/9 11550 20000000
16QAM TRE 3/4 13200 20000000
16QAM TRE 7/8 15400 20000000
MN-DMD1050 6–4
Revision 9
