DMD1050 Satellite Modem Board Technical Specifications
188 Mode
Modulation Code Rate Min Data Rate Max Data Rate
BPSK VIT 1/2 2400 4607843
BPSK VIT 2/3 2950 6143790
BPSK VIT 3/4 3318 6911764
BPSK VIT 5/6 3687 7679738
BPSK VIT 7/8 3871 8063725
QPSK VIT 1/2 4424 9215686
QPSK VIT 2/3 5899 12287581
QPSK VIT 3/4 6636 13823529
QPSK VIT 5/6 7373 15359476
QPSK VIT 7/8 7742 16127450
8PSK TRE 2/3 8848 18431372
8PSK TRE 5/6 11059 20000000
8PSK TRE 8/9 11797 20000000
16QAM TRE 3/4 13271 20000000
16QAM TRE 7/8 15483 20000000
204 Mode
Modulation Code Rate Min Data Rate Max Data Rate
BPSK VIT 1/2 2400 5000000
BPSK VIT 2/3 3200 6666666
BPSK VIT 3/4 3600 7500000
BPSK VIT 5/6 4000 8333333
BPSK VIT 7/8 4200 8750000
QPSK VIT 1/2 4800 10000000
QPSK VIT 2/3 6400 13333333
QPSK VIT 3/4 7200 15000000
QPSK VIT 5/6 8000 16666666
QPSK VIT 7/8 8400 17500000
8PSK TRE 2/3 9600 20000000
8PSK TRE 5/6 12000 20000000
8PSK TRE 8/9 12800 20000000
16QAM TRE 3/4 14400 20000000
16QAM TRE 7/8 16800 20000000
MN-DMD1050 6–5
Revision 9
