DMD1050 Satellite Modem Board DMD1050 Strap Codes
Table G-1. DMD1050 Strap Codes
Dis = Disable
Strap Code
(Decimal)
Data Rate (Kbps)
Overhead
Code Rate
Type
Framing Type
Scrambler Type
Reed-Solomon
Modulation
Mode
66 256 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK CNT
68 320 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK CNT
72 320 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK CNT
80 384 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
96 384 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
129 512 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
130 512 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
132 768 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
136 768 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
144 896 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
44 896 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
7 1344 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
11 1344
1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
13 1536 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
14 1536 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
19 1544 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
21 1544 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
22 1920 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
25 1920 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
26 2048 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
28 2048 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
37 2368 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
38 2368 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
41 48 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK CNT
69 6312 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK CNT
70 8448 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
73 3152 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
74 3152 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
76 3264 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
81 3264 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
97 1024 1 1/2 VIT CNT V.35 (IESS) Dis QPSK CNT
