DMD1050 Satellite Modem Board DMD1050 Strap Codes
Table G-1. DMD1050 Strap Codes
Dis = Disable
Strap Code
(Decimal)
Data Rate (Kbps)
Overhead
Code Rate
Type
Framing Type
Scrambler Type
Reed-Solomon
Modulation
Mode
98 1024 1 3/4 VIT CNT V.35 (IESS) Dis QPSK CNT
134 192 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
137 192 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
138 320 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
140 320 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
100 448 16/15 1/2 VIT IBS IBS Dis QPSK CNT
146 448 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
104 576 16/15 1/2 VIT IBS IBS Dis QPSK CNT
148 576 16/15 3/4 VIT IBS IBS Dis QPSK CNT
152 640 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
161 640 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
162 704 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
164 704
16/15 3/4 VIT IBS IBS Dis QPSK
CNT
193 832 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
194 832 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
196 896 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
208 896 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
224 960 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
15 960 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
30 1088 16/15 1/2 VIT IBS IBS Dis QPSK CNT
39 1088 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
43 1152 16/15 1/2 VIT IBS IBS Dis QPSK CNT
46 1152 16/15 3/4 VIT IBS IBS Dis QPSK CNT
51 1216 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
53 1216 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
54 1280 16/15 1/2 VIT IBS
IBS Dis QPSK
CNT
57 1280 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
58 1344 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
67 1408 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
71 1408 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
75 1472 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
MN-DMD1050 G–3
Revision 9
