DMD1050 Satellite Modem Board DMD1050 Strap Codes
Table G-1. DMD1050 Strap Codes
Dis = Disable
Strap Code
(Decimal)
Data Rate (Kbps)
Overhead
Code Rate
Type
Framing Type
Scrambler Type
Reed-Solomon
Modulation
Mode
77 1472 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
78 1600 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
83 1600 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
85 1664 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
86 1664 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
89 1728 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
90 1728 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
92 1792 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
99 1792 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
102 1856 16/15 1/2 VIT IBS IBS Dis QPSK
CNT
105 1856 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
106 2048 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
135 1984
16/15 1/2 VIT IBS IBS Dis QPSK
CNT
139 1984 16/15 3/4 VIT IBS IBS Dis QPSK CNT
45 3088 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
141 3088 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK CNT
176 4000 1 1/2 VIT
NONE
V.35 (IESS) Dis QPSK CNT
116 4000 1 3/4 VIT
NONE
V.35 (IESS) Dis QPSK
CNT
60 1344 16/15 3/4 VIT IBS IBS Dis QPSK
CNT
