DMD1050 Satellite Modem Board User Interface Connections
J3 & J7 Information on Supplied Interface Connectors for DC & BUC Power
J7 DC input Power - 4 Pin Crimp Terminal Hsg: Mfg (Molex) P/N: 09-50-3041
J3 BUC/LNB input - 4 Pin Crimp Terminal Hsg: Mfg (Molex) P/N: 09-50-3041
MN-DMD1050 E–3
Revision 9
