Concordia Integra - Diagram 6, Parts List: Brew Group Assembly

3029-015B Section 15: Parts List & Diagrams
Concordia Integra Technical Support Manual 15-15
2900-255B
Diagram 6, Parts List: Brew Group Assembly
Diagram 6
Item #
Description
Available
Concordia
Part
Number
1
ASSY BREW GROUP I4
YES
2150-020
2
MICRO SCREEN UPPER PISTON
YES
1110-446
3
ARM SWEEP 1.5K
YES
1110-611
NS
PLATE GROUP ADAPTER I4
YES
1110-714
4
PLATE BREW GRP TOP I4
YES
1110-750
5
BRKT NO-BEAN SENSING I4
YES
1110-780
6
BASE PIVOT SWEEP ARM
YES
1120-230
7
ELBOW 1/8NPT X 1/4T
YES
1232-097
NS
HALF CARTRIDGE 1/4
YES
1232-099
NS
ADAPT 1/8BSPP X 1/4JG
YES
1233-019
NS
TUBE PFA 5/32 ID X 1/4 OD
YES
1250-006
8
O RING UPR PISTON 1K/1.5K
YES
1260-072
9
SW TEMP GROUP 60C
YES
1311-032
NS
PIN M AMP MED
YES
1353-009
NS
TUBE HEAT SHR 1.5 BLK
YES
1383-021
10
PH PHIL MS SS 6-32 X 1/4
YES
1410-007
12
PH PHIL SMS SS 6 X 3/8
YES
1410-121
13
SHLDR SS 1/4LX5/32WX6-32
YES
1410-129
14
FH PHIL SS M4X12
YES
1410-135
15
CH SLOT SS- M4 X 8
YES
1410-169
16
WASHER FLAT #8
YES
1430-011
17
WSHR WAVE .40ID X .61OD
YES
1430-039
18
ASSY GRP HTR I4
YES
2150-021
19
SENSOR-GROUP-IR-1000i
YES
2160-004
20
ASSY- ADAPT- 5/32T X 1/4T
YES
2340-034
24
CBL-GROUP IR-1000i
YES
2670-132
21
KIT F3 GRP UPPER PISTON
YES
2150-019
or
98007
22
COTTER PIN
YES
1451-036
23
CLIP LOCKING 1/4
YES
1454-055
NS
CBL-GROUP IR-1000i
YES
2670-132
