Conel FLOW CUT BOX - Exploded View

12.
Exploded view
Figure 9
Pos Descripon Pos Descripon
1
Cover
5
Level sensor
2
Cover securing screw
6
Discharge pipe
3
Motor/pumping unit securing screws 7 Shredding system
4
Motor/pumping unit 8 Capacitor housing
/ Totakeoutthepumpingunitforservice,removesecuringscrew(2)andliocover(1).
/ Removesecuringscrews(3)andlipumpingunit(4)fromtank(seeg.9).
ATTENTION!
Neveroperatetheliingunitwithouttheprotecvecover(1)securelyed.
1
2
1
2
3
4
5 6 7 8
42
