Conel FLOW CUT BOX - Set Up;Installation; For Ground Set up

8.
Set up/installation
ATTENTION! The relevant standards must be observed.
For use below the backwash level:
/ Guide the discharge line with a loop above the backwash level.
/ Ifthebaseofthedischargelineloopismorethan5mabovetheliingunit,anaddional
checkvalve must be installed.
/ Provideshutovalves.
/ Everydrainmustbeedwithanodourtrap.
Alsoseeinstallaondimensions(chapter18,page46-47,gure14).
8.1
For ground set up
ATTENTION!
/ The set up must be made frost-free and on level ground.
Connection of discharge pipe
/ Use a PVC discharge pipe with an outside diameter of 25 or 32 mm.
/ Push the pipe to about 16 mm into the rubber sleeve (use a lubricant if necessary) and secure it on
theoutsidewiththeexisnghoseclamp.
Figure 1
Fing of non-return valve
A=Flowmustfollowdireconofarrow.
C = Flap must hinge from the top with arrow
poinngdown.
Figure 2
1
2
3
4
AC
Pos Descripon
1
Non-return valve
2
Discharge line (right)
3
Dischargeline(le)
4
Cap for unused end of
discharge line
1
2
3
4
AC
37
