Conel FLOW CUT BOX - Page 38

Installaon of securing brackets
Keepstheliingunitsafelyinplace,evenincaseofooding.
1.Placetheliingunitinthedesiredinstallaonlocaon.
2. Secure unit to the ground with the aid of the brackets.
Figure 3
Side inlets DN 50
1.Removethestopper(1)fromthedesiredDN50inletconnecontorevealtheedrubberseal(2).
2. Push the supply line DN 50 (3) approx. 16 mm into the rubber seal (use a lubricant if necessary).
Figure 4
Separate vent line
1. Forodour-sensiveapplicaons,
e.g.indoctor‘soces,venttheunitabovetheroof.
2. Removetheltercoverandthecarbonlter(seepage43,g.10).
3. Push the vent line into the rubber seal (use a lubricant if necessary).
Figure 5
DN 50
DN 50
1
2
3
DN 50
DN 50
1
2
3
DN 50
DN 50
1
2
3
VenlaonpipeDN50
Seal
38
