Conel FLOW CUT BOX - Page 39

Toilet connecon
/ FLOWCBisdesignedbothfordirectconnecontothefrontoftheunitwheninstalleddirectly
behindthetoilet(setupA),orforsideconnecontoasewagepipewheninstalledbehinda
paron(setupB).
/ Theunusedinletissealedusingthepush-tsealingcap(4)andseal(3).
/ Thesealingsleeve(1)isaachedtotheunitbytheclip-onringclamp(2).
Figure 6
Pos Descripon
1
DN 100 sealing sleeve
2
Clamp ring
3
Seal
4
Sealing cap
ATTENTION!
Wheninstalledbehindaparontheunitshouldbeventedexternallyusingaventpipe(seepage38,
gure5).
Ifnotpossibleaspecialvenngkitisavailable(seepage43,chapter14).
1
2
2
3
A
B
1
3
4
4
39
