Internal Connector Summary
Designator
Connector
Description
P1
0353180420
+9V to +36V Mini-Fit Jr. 4-Pin DC Power Input Connector
P2
SM3ZS067U410ABR1000
M.2 3042 B-Key 2G/3G/LTE Cellular Module Connector
P3
SM3ZS067U410AER1000
M.2 2230 E-Key WiFi/Bluetooth Module Connector
P4A
P4B
1-2199230-5
1-2199119-5
M.2 2280 M-Key NVMe SSD Connector
P5A
P5B
2007435-3 HDMI Video Connector
P6
JXD1-2015NL
Dual RJ-45 Gigabit Ethernet Connector
P7
0475530001
SIM Card Connector
P8A
P8B
2304168-9 GMSL 1/2 Quad FAKRA Camera Connector
P9A
P9B
TFM-103-02-L-DH-TR 6 Pin Isolated CAN Connector
P10
TFM-120-02-L-DH-TR
40 Pin GPIO Connector
P11
10067847-001RLF
SD Card Connector
P12A
P12B
48404-0003 USB3.0 Type-A Connector
P13A
P13B
48404-0003 USB3.0 Type-A Connector
P14
632723300011
USB3.0 Type-C Connector w/ OTG
P15
203456-0003
699 Pin Mirror Mezz Xavier AGX Connector
BAT1
BHSD-2032-SM
CR2032 RTC Battery Connector
