External Connector Summary
Location
External Connector
Description
Front
PWR IN
+9V to +36V Mini-Fit Jr. 4-Pin DC Power Input Connector
Front
HDMI 1, 2
HDMI Video Connectors
Back
OTG
USB 3.0 Type-C OTG Connector
Back
GbE1, GbE2
Dual RJ-45 Gigabit Ethernet Connector
Front
SD CARD
SD Card Connector
Front
SIM CARD
SIM Card Connector
Back
USB 1, 2, 3, 4
USB3.0 Type-A Connector
Front
EXPANSION I/O
40 Pin GPIO Connector
Front
GMSL 1, 2
GMSL 1/2 Quad Camera Connectors
Front
CAN A, B
6 Pin Isolated CAN Connectors
Front
RESET
FORCE RECOVERY
Reset and Force Recovery Pushbuttons
Back
ANT 1, 2
Antenna
Front
ANT 3, 4
Antenna
Jumper Summary & Locations
Designator
Connector
Description
SW2
SW3
TL1260BQRBLK
Reset and Force Recovery Pushbuttons
