Rudi-AGX USB 3.0 Type-C Connector w/ OTG
The Rudi-AGX implements a USB3.0 Type-C connector to allow host mode access to the module or OTG
flashing of the module.
Function
Description
Location
Rear
Type
Type-C USB Connector
Mating
Connector
USB 3.0 Type-C
Pinout
Refer to USB Standard
Rudi-AGX SD Card Connector
The Rudi-AGX implements a Full-Size SD Card connector.
Function
Description
Location
Front
Type
SD Card Connector
Pinout
Refer to SD Card Standard
Rudi-AGX SIM Card Connector
The Rudi-AGX implements a Standard Size SIM Card connector.
Function
Description
Location
Front
Type
SIM Card Connector
Pinout
Refer to SIM Card Standard
