DETAILED FEATURE DESCRIPTION
Rudi-AGX NVIDIA® Jetson AGX Xavier™ Module Connector
The NVIDIA® Jetson AGX Xavier™ processor and chipset are implemented on the Jetson AGX Xavier™
Module. This connects to the AGX Xavier module to the Rudi-AGX via Molex Mirror Mezz 699 pin
connector.
Function
Description
Location
Embedded within Rudi-AGX
Type
Module
Pinout
Refer to NVIDIA® Jetson AGX
Xavier™ Datasheet.
Features
Refer to NVIDIA® Jetson AGX
Xavier™ Datasheet.
Note: A Thermal Transfer Plate is incorporated on the NVIDIA® Jetson AGX Xavier™ module that dissipates heat through the top
of the Rudi-AGX Chassis.
