Rudi-AGX HDMI Connector
The NVIDIA® Jetson AGX Xavier™ module will output video via the dual vertical HDMI connectors that
are HDMI 2.0 capable.
Function
Description
Location
Front
Type
HDMI Vertical Connector
Mating
Connector
HDMI Type-A Cable
Pinout
Refer to HDMI Standard
