POWER CONSUMPTION & THERMALS
The Rudi-AGX has an Operating Temperature Range of -25°C to +60°C.
However, it is important to note that the NVIDIA® Jetson AGX Xavier™ module has its own properties
separate to that of the peripherals.
Customer responsibility requires proper implementation of a thermal solution that maintains the Rudi-
AGX temperatures below the specified temperatures (shown in the tables below) under the maximum
thermal load and system conditions for their use case.
NVIDIA® Jetson AGX Xavier™
Parameter
Value
Units
Maximum AGX Xavier SoC Operating Temperature
T.cpu = 90.5
°C
T.gpu = 91.5
°C
T.aux = 90.0
°C
AGX Xavier SoC Shutdown Temperature
T.cpu = 96.0
°C
T.gpu = 97.0
°C
T.aux = 95.5
°C
Rudi-AGX
Parameter
Value
Units
Maximum Operating Temperature @125CFM
No M.2 Peripherals Installed
T.cpu = 90.5
°C
T.gpu = 93.0
°C
T.amb = 60.0
°C
Parameter
Value
Units
Value
Units
Temperature
Rudi-AGX Theoretical Maximum
19
V
TBD
W
25°C (typ.)
Rudi-AGX, NVIDIA® Jetson AGX Xavier™ Module
Installed, Fully-Booted, Idle, Passive Cooling
19 V TBD W 25°C (typ.)
Rudi-AGX, NVIDIA® Jetson AGX Xavier™ Module
Installed, Fully-Booted, 100% CPU, 100% GPU, 100%
NVMe(s), 125CFM Airflow
19 V TBD W 25°C (typ.)
