Users Guide
Document: CTIM-00051
Revision: 0.01
Page 24 of 29 Date: 2021-03-22
TYPICAL INSTALLATION
1. Ensure all external system power supplies are off and disconnected.
2. Install the necessary cables for your application. At a minimum these would include:
a) Power cable to the input power connector.
b) Ethernet cable into its port (if applicable).
c) HDMI video display cable (if applicable).
d) Keyboard, Mouse, etc. via USB (if applicable).
e) SD Card (if applicable).
f) SIM Card (if applicable).
g) GMSL Camera(s) (if applicable).
h) GPIO 40-Pin Connector (if applicable).
i) CAN 6-Pin Connector (if applicable).
j) Antennas for WiFi/Bluetooth (if applicable).
k) Antennas for Cellular (if applicable).
3) Connect the Power Cable of the +9V to +36V Power Supply into the Mini-Fit Jr. 4-Pin power
connector.
4) Plug the AC cable into the Power Supply and into the wall socket.
DO NOT power up your system by plugging in live power.
