Rudi-AGX Antenna Connectors
The Rudi-AGX chassis implements 4x SMA Antenna Connectors (Optional) for the internal M.2 2230 E-
Key (WiFi/Bluetooth) and M.2 3042 B-Key (Cellular).
Function
Description
Location
Front and Rear
Type
SMA Connector
Mating
Connector
Antenna Connector
