16
Violet
I2C0_SCL
(3.3V Max.)
I/O
17
Gray
I2C0_SDA
(3.3V Max.)
I/O
18
White
GND
Power
19
Black
I2C2_SCL
(3.3V Max.)
I/O
20
Blue
I2C2_SDA
(3.3V Max.)
I/O
21
Brown
GND
Power
22
Red
GPO12 (3.3V Max.)
O
23
Orange
GPO13 (3.3V Max.)
O
24
Yellow
GPI14 (3.3V Max.)
I
25
Green
GPI17 (3.3V Max.)
I
26
Violet
GND
Power
27
Gray
GPO18
(3.3V Max.)
O
28
White
GPI19
(3.3V Max.)
I
29
Black
GND
Power
30
Blue
RXD+ (RS485)
I
31
Brown
RXD- (RS485)
I
32
Red
TXD+ (RS485)
O
33
Orange
TXD- (RS485)
O
34
Yellow
RTS (RS485)
O
35
Green
+5V
Power
36
Violet
UART1_TX
(3.3V Max.)
O
37
Gray
UART1_RX
(3.3V Max.)
I
38
White
+3.3V
Power
39
Black
GND
Power
40
Blue
GND
Power
