6
Step2. Put another end of the cord through the first one and then tighten it.
7. Operating Guide
7.1 Let the patient’s finger put into the rubber cushions of the clip (make sure the finger is in the
right position), and then clip the finger.
a) Press the Power Button on the front panel.
b) Using first finger, middle finger or ring finger when doing test. Low finger temperature, fat
finger, thin finger may cause inaccurate measurement.
c) Do not shake the finger and keep the patient at ease during the process.
7.2 Get the information directly from screen display.
Put the finger in the oximeter like Figure 3.
Figure 3 Finger Placed
7.3 This product has the function of USB communications.
Firstly setup the USB driver in the computer (See details in CD), store the oximeter users’
software in the computer, open the user’s interface, then connect the oximeter and the computer
with the USB cable to fulfill the communication.
NOTE: This function is only used to data-transfer to the computer, but no downloading.
7.4 When working, the display direction can be changed by pressing the button shortly. There are
four modes of direction.
Press the button long time to enter the following menu interface- Figure 4 ( When the display
direction on the screen is plumb with the finger input direction, you cannot enter the menu
interface, press the button shortly again, let the display direction on screen level with the finger
input direction, continue next step): The user can setup the following parameters in
menu—lightness of backlight, alarm and high-low limit, data transmission( with USB cable),
data store, data upload to computer( with USB cable). See details as following:
To Next Page
