2. Specifications
Function Specifications
Table 2.1. Function Specifications < 1 / 2 >
Specification
Item
IPC-DT/M20V(PC)T IPC-DT/L20S(PC)T IPC-DT/H20X(PC)T
Screen
Assembly type Panel mounted *1
Screen size 10.4 inches 12.1 inches 15 inches
Number of pixels 640 x 480 dots 800 x 600 dots 1024 x 768 dots
Display type TFT Color LCD
Number of colors 262,144 colors 262,144 colors 16,777,216 colors
Screen adjustment Automatic adjustment (display positioning and scaling) and manual adjustment
using the front switches
Brightness control Adjustment using the front switch or software control from the host computer
Backlight control
Adjustment using the front switch, software control from the host computer, or
ON/OFF control via the rear-panel connector input
Display interface Analog RGB input HD-SUB 15 pin (Female) connector
Cable length which recommends 5mm or less *2
Picture signal RGB separation, Analog, Positive polarity 0.7Vp-p/75Ω
Synchronized
signal
V/H separation, TTL, Positive / negative polarity
Horizontal scan
frequency
31 - 38kHz 31 - 48kHz 31 - 60kHz
Incoming signal
specification
Vertical scan
frequency
60 - 72Hz 56 - 72Hz 56 - 75Hz
Touch panel
Resolution 4096 x 4096
Detection method Resistive-layer analog method
Touch life expectancy One million repeated touches (silicon rubber load of 3 N)
Touch panel interface Connect to the host computer using either USB*3 or RS-232C.
USB: USB1.1-compliant, TypeB Connector
RS-232C: 9pin D-SUB (Male) Connector
Touch panel driver
(Option)
Windows : IPC-SLIB-01
MS-DOS : IPC-TPB1-DRV
