3. Outside Dimensions and Part Names
12
User’s Manual
IPC-DT/H20X(PC)T
[mm]
302
4-M4 TAP(Including the mate)
(Maximum tapping length:4mm)
4-M4 TAP(Including the mate)
(Maximum tapping length:4mm)
4-M4 TAP
(Maximum tapping length:4mm)
15.5
12-M4 STUD
48
13
2.4
336
106
304
106 107
100
100
428
396
137 137 137
(96.7)
(22.3)
15.5
254
7
233.1
309.1
157.5
138
Figure 3.3. Outside Dimensions of Main Unit
(IPC-DT/H20X(PC)T)
IPC-DT/M20V(PC)T with IPC-POA200/12-01
(power supply unit)
2.4
54
44
(1.5)
[mm]
Figure 3.4. Dimensions of IPC-DT/M20V(PC)T with
IPC-POA200/12-01
