4. Setting the Display
22
User’s Manual
Attaching the Fitting Used to Attach to the Main Unit
IPC-DT/M20V(PC)T
1. Hold the main unit from the outside of the panel.
Figure 4.6. Attaching the Fitting Used to Attach to the
Main Unit < 1 / 4 >
2. Hold the attach from the inside of the panel.
Figure 4.6. Attaching the Fitting Used to Attach to the
Main Unit < 2 / 4 >
